ALOYCO 2374C02010 FIG 2374 Swing Check Valve, 1" Nominal, Socket Weld End Style, 300 lb, Stainless Steel Body, Bolted Cover
CBPN:256175
MPN:2374C02010
Price:
$839.58 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 2374, 1 in Nominal, Socket Weld, 300 lb, CF8M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
ALOYCO 2374C02010 FIG 2374 Swing Check Valve, 1" Nominal, Socket Weld End Style, 300 lb, Stainless Steel Body, Bolted Cover
CBPN:256175
MPN:2374C02010
Price:
$839.58 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 2374, 1 in Nominal, Socket Weld, 300 lb, CF8M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 5.8 lbs
Nominal Size: 1 in
End Style: Socket Weld
Pressure Class: 300 lb
Softgoods Material: PTFE
Body Material: Stainless Steel
Inlet to Outlet Length: 4.13 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 3.4 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Integral Seat
- Recessed Retained Gasket
- API Trim 10 (316 SS)
