WATTS® 0823051

WATTS® 0823051 77F-BI Wye Strainer, 4 in Nominal, 14-3/8 in OAL, Flanged x NPT Tap Connection, PTFE Softgoods, Import

CBPN:234444

UPC:098268880908

MPN:0823051

Price:
$14429.43 / EA

DESCRIPTION

WATTS® Wye Strainer, Series: 77F-BI, 4 in Nominal, 14-3/8 in Overall Length, Flanged x NPT Tap, 1-1/2 in NPT Blow-Off, PTFE, Cast Bronze Body, Import

Series 77F-BI Bronze, Flanged, Wye-Pattern Strainers are used in liquid and steam applications. Series 77F-BI are furnished with blowdown connections and machined seat that allows the screen to be self-aligning and assures a perfect fit. All sizes come with a bolted screen retainer cover and PTFE gasket. The screen retainer cover is NPT tapped for a blowdown plug that is provided. The strainer is easily cleaned by removing the blowdown plug or opening a blowdown valve piped to the blowdown outlet. Series 77F-BI can be installed in horizontal or vertical pipe with the blowdown connection at the lower end of the screen retainer cover.

WATTS® 0823051 77F-BI Wye Strainer, 4 in Nominal, 14-3/8 in OAL, Flanged x NPT Tap Connection, PTFE Softgoods, Import

CBPN:234444

MPN:0823051

UPC:098268880908

Price:
$14429.43 / EA

Watts logo

DESCRIPTION

WATTS® Wye Strainer, Series: 77F-BI, 4 in Nominal, 14-3/8 in Overall Length, Flanged x NPT Tap, 1-1/2 in NPT Blow-Off, PTFE, Cast Bronze Body, Import

Series 77F-BI Bronze, Flanged, Wye-Pattern Strainers are used in liquid and steam applications. Series 77F-BI are furnished with blowdown connections and machined seat that allows the screen to be self-aligning and assures a perfect fit. All sizes come with a bolted screen retainer cover and PTFE gasket. The screen retainer cover is NPT tapped for a blowdown plug that is provided. The strainer is easily cleaned by removing the blowdown plug or opening a blowdown valve piped to the blowdown outlet. Series 77F-BI can be installed in horizontal or vertical pipe with the blowdown connection at the lower end of the screen retainer cover.

Specifications

BrandWATTS®
Nominal Size4 in
Body MaterialCast Bronze
Connection TypeFlanged x NPT Tap
Softgoods MaterialPTFE
Overall Length14-3/8 in
Blow-Off Size1-1/2 in NPT
Manufacturer NameWatts Water Technologies
Series77F-BI
ApplicationCommercial and Industrial
Domestic/ImportImport
Country of OriginCN
Standards and ApprovalsASTM B-62 Plug | ASTM B-62 Screen Cover

Item Features

  • Class 150 flanged
  • Flanged wye-pattern
  • Self-aligning stainless steel screen
  • Screen retainer cover tapped and plugged
  • PTFE gasket

Standards

ASTM B-62 Plug|ASTM B-62 Screen Cover
