WATTS® 0547102

WATTS® 0547102 FBV-3C 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Forged Brass Body, Full Port, Fluorocarbon/Virgin PTFE Softgoods, Import

CBPN:152409

UPC:098268335958

MPN:0547102

Price:
$9.26 / EA

DESCRIPTION

WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 1/2 in Nominal, FNPT End Style, 600 psi Pressure, -40 to 400 deg F, Full Port, Media: Gas/Liquids, Chrome Plated Brass Ball, 1-15/16 in Inlet to Outlet Length, 1-13/16 in Top to Inlet Center, Forged Brass Body, Brass Stem and PTFE Seat Trim, Fluorocarbon/Virgin PTFE Softgoods, Import

Series FBV-3C, FBVS-3C 2-Piece, Full Port, Brass Ball Valves are used in commercial and industrial applications for a full range of liquids and gases. They feature a bottom-loaded blow-out proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter, and steel handle. Model FBV-3C has threaded end connections. Model FBV-3C-TH has tee handle with threaded connections. Model FBVS-3C has solder end connections. Model FBVS-3C-TH has tee handle with solder connections.

WATTS® 0547102 FBV-3C 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Forged Brass Body, Full Port, Fluorocarbon/Virgin PTFE Softgoods, Import

CBPN:152409

MPN:0547102

UPC:098268335958

Price:
$9.26 / EA

Watts logo

DESCRIPTION

WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 1/2 in Nominal, FNPT End Style, 600 psi Pressure, -40 to 400 deg F, Full Port, Media: Gas/Liquids, Chrome Plated Brass Ball, 1-15/16 in Inlet to Outlet Length, 1-13/16 in Top to Inlet Center, Forged Brass Body, Brass Stem and PTFE Seat Trim, Fluorocarbon/Virgin PTFE Softgoods, Import

Series FBV-3C, FBVS-3C 2-Piece, Full Port, Brass Ball Valves are used in commercial and industrial applications for a full range of liquids and gases. They feature a bottom-loaded blow-out proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter, and steel handle. Model FBV-3C has threaded end connections. Model FBV-3C-TH has tee handle with threaded connections. Model FBVS-3C has solder end connections. Model FBVS-3C-TH has tee handle with solder connections.

Specifications

BrandWATTS®
Nominal Size1/2 in
End StyleFNPT
Pressure Rating600 psi
Body MaterialBrass
Port TypeFull
Softgoods MaterialFluorocarbon/Virgin PTFE
Ball MaterialChrome Plated Brass
Inlet to Outlet Length1-15/16 in
Manufacturer NameWatts Water Technologies
MediaGas/Liquids
SeriesFBV-3C
Temperature Rating-40 to 400 deg F
Top to Inlet Center1-13/16 in
Trim MaterialBrass Stem and PTFE Seat
Type2-Piece
ApplicationCommercial and Industrial Applications
Warranty1 year Limited
Domestic/ImportImport
Country of OriginCN
Standards and ApprovalsASME B16.33/B16.44 | CSA Certified | FM Approved | MSS-SP-110 Compliant | UL Listed

Item Features

  • Made of durable brass
  • Fluorocarbon elastomer stem O-Ring prevents stem leaks
  • Adjustable stem packing gland nut
  • Bottom loaded, blow-out proof stem
  • Machined chrome plated brass ball
  • Recommended for open/close applications
  • 150 psi steam working pressure
  • Fluorocarbon elastomer O-ring and virgin PTFE stem packing seal/thrust washer
