Tylok CS-Lok Union

Tylok® CS-Lok® B-4-SU SU Series Single Ferrule Union, 1/4 in, Tube, Brass, Domestic

CBPN:183816

UPC:811731022595

MPN:B-4-SU

Price:
$6.47 / EA
Enter in multiples of 10

DESCRIPTION

Tylok® CS-Lok® Union, Single Ferrule, Series:SU Series, Union, 1/4 in Nominal, Tube, 1/2 in Hex, 1.62 in Length, Brass, Domestic

CS-Lok® tube fittings is fully interchangeable with Parker CPI™. Although it is always recommended to use all CS-Lok® components, intermixing CS-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CS-Lok® Tube Fittings are made to strict quality control standards and cannot guarantee that of other manufacturers. CS-Lok® Tube Fittings are proudly made in the U.S.A.

Tylok® CS-Lok® B-4-SU SU Series Single Ferrule Union, 1/4 in, Tube, Brass, Domestic

CBPN:183816

MPN:B-4-SU

UPC:811731022595

Price:
$6.47 / EA

Enter in multiples of 10
Tylok logo

DESCRIPTION

Tylok® CS-Lok® Union, Single Ferrule, Series:SU Series, Union, 1/4 in Nominal, Tube, 1/2 in Hex, 1.62 in Length, Brass, Domestic

CS-Lok® tube fittings is fully interchangeable with Parker CPI™. Although it is always recommended to use all CS-Lok® components, intermixing CS-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CS-Lok® Tube Fittings are made to strict quality control standards and cannot guarantee that of other manufacturers. CS-Lok® Tube Fittings are proudly made in the U.S.A.

Specifications

BrandTylok®
Weight0.05 lbs
Fitting/Connector TypeUnion
TypeSingle Ferrule
Nominal Size1/4 in
End StyleTube
MaterialBrass
Hex Size1/2 in
Length1.62 in
Manufacturer NameTylok International
SeriesSU Series
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM B16 Alloy 360/ASTM B453 Alloy 345 Bar Stock | ASTM B124 Alloy 377 Forging | ASTM B75 Copper Temper (O) Tubing | ABS | ASTM F1387 | Canadian Registration | ISO 9001:2008

Item Features

  • Single ferrule swaging action
  • Total component interchangeability
  • More tolerant of vibrations
  • Heat code traceable
  • ASTM material construction
  • 9/16 in nut
  • 1/4-18 NPT pipe thread
  • 60 max rockwell 15 T hardness
  • Interchanges with 4-4 HBZ
