Trerice D82LFB2502BA100 D80 Industrial Pressure Gauge, 0 to 100 psi Pressure, 1/4 in MNPT Connection, 2-1/2 in Dia Dial, +/- 1.6 % Accuracy, Glycerin Liquid Filled
CBPN:150587
UPC:842615101358
MPN:D82LFB2502BA100
Price:
$24.03 / EA
DESCRIPTION
Trerice Industrial Pressure Gauge, Series: D80, 0 to 100 psi Pressure, 1/4 in MNPT Connection, 2-1/2 in Diameter Dial, +/- 1.6 % Accuracy, Liquid Filled: Glycerin, 150 deg F, Rear Mounting, 304 Stainless Steel Case, 2.68 in Dia x 1.18 in D Dimensions
The Trerice D80 Series Industrial Gauge is designed for rugged performance requirements at an economical cost. This liquid filled gauge is furnished with a stainless steel case and crimped ring. Wetted parts are either bronze tube with Lead-Free (PBF) brass socket or stainless steel.
Trerice D82LFB2502BA100 D80 Industrial Pressure Gauge, 0 to 100 psi Pressure, 1/4 in MNPT Connection, 2-1/2 in Dia Dial, +/- 1.6 % Accuracy, Glycerin Liquid Filled
CBPN:150587
MPN:D82LFB2502BA100
UPC:842615101358
Price:
$24.03 / EA
DESCRIPTION
Trerice Industrial Pressure Gauge, Series: D80, 0 to 100 psi Pressure, 1/4 in MNPT Connection, 2-1/2 in Diameter Dial, +/- 1.6 % Accuracy, Liquid Filled: Glycerin, 150 deg F, Rear Mounting, 304 Stainless Steel Case, 2.68 in Dia x 1.18 in D Dimensions
The Trerice D80 Series Industrial Gauge is designed for rugged performance requirements at an economical cost. This liquid filled gauge is furnished with a stainless steel case and crimped ring. Wetted parts are either bronze tube with Lead-Free (PBF) brass socket or stainless steel.
Specifications
Brand: Trerice
Weight: 0.45 lbs
Pressure Range: 0 to 100 psi
Dial Diameter: 2-1/2 in
Connection Size: 1/4 in MNPT
Mounting Type: Rear
Accuracy: +/- 1.6 %
Liquid Filled: Glycerin
Dimensions: 2.68 in Dia x 1.18 in D
Manufacturer Name: H.O. Trerice
Material: 304 Stainless Steel Case
Series: D80
Temperature Rating: 150 deg F
Application: For broad spectrum of industrial needs
Standards and Approvals: ASME B40.100 Grade 1A | cULus Water Quality MH59892 | CNR Registered | NSF/ANSI 372/61
Item Features
- Brass movement
- Plain, black finished pointer
- Bronze tube, brass socket
- Acrylic window
- 304 stainless steel, stem mounted flangeless case
- Aluminum/white background with black graduations and markings dial face
- Crimped 304 stainless steel ring
