Titan® CV12S0250 CV12-SS Short Pattern Wafer Swing Check Valve, 2-1/2 in Nominal, Flanged End Style, 150 lb, PTFE Softgoods, Stainless Steel Body
CBPN:251150
UPC:046564016187
MPN:CV12S0250
Price:
$254.67 / EA
DESCRIPTION
Titan® Swing Check Valve, Short Pattern Wafer, Series: CV12-SS, 2-1/2 in Nominal, Flanged End Style, 275 psi WOG Pressure, 150 lb Pressure Class, 100 deg F, No Low Lead Compliance, Reduced Port, 0.55 in Inlet to Outlet Length, Stainless Steel Body, PTFE/Stainless Steel Trim, PTFE Softgoods, 4.9 in Dia
Check Valves are automatic shut-off valves that are commonly used for preventing backflow or drainage in a piping system. Often applied on the discharge side of pumps, check valves prevent the system from draining if the pump stops and protect against backflow, which could harm the pump or other equipment.
Titan® CV12S0250 CV12-SS Short Pattern Wafer Swing Check Valve, 2-1/2 in Nominal, Flanged End Style, 150 lb, PTFE Softgoods, Stainless Steel Body
CBPN:251150
MPN:CV12S0250
UPC:046564016187
Price:
$254.67 / EA
DESCRIPTION
Titan® Swing Check Valve, Short Pattern Wafer, Series: CV12-SS, 2-1/2 in Nominal, Flanged End Style, 275 psi WOG Pressure, 150 lb Pressure Class, 100 deg F, No Low Lead Compliance, Reduced Port, 0.55 in Inlet to Outlet Length, Stainless Steel Body, PTFE/Stainless Steel Trim, PTFE Softgoods, 4.9 in Dia
Check Valves are automatic shut-off valves that are commonly used for preventing backflow or drainage in a piping system. Often applied on the discharge side of pumps, check valves prevent the system from draining if the pump stops and protect against backflow, which could harm the pump or other equipment.
Specifications
Brand: Titan®
Weight: 3.5 lbs
Nominal Size: 2-1/2 in
End Style: Flanged
Pressure Class: 150 lb
Low Lead Compliance: No
Softgoods Material: PTFE
Body Material: Stainless Steel
Dimensions: 4.9 in Dia
Inlet to Outlet Length: 0.55 in
Manufacturer Name: Titan Flow Control
Port Type: Reduced
Pressure Rating: 275 psi WOG
Series: CV12-SS
Temperature Rating: 100 deg F
Trim Material: PTFE/Stainless Steel
Type: Short Pattern Wafer
Application: Oil and Gas Production, General, Chemical and Petrochemical Industries
Standards and Approvals: ANSI 150 | API 598/ANSI B16.5 | ASME/ANSI B16.34 | ASTM A240 Grade 316 Body | A351-CF8 Disc
Item Features
- Robust design - This is a self-acting, non-return, single plate, wafer type swing check valve which provides high quality and reliability with in a simplified construction
- Minimal head loss - The low inertia disc is designed to open and close under low differential pressure conditions, also the short pattern design and straight flow path minimize pressure drop across the valve
- Economical design - The low weight and short face-to-face dimensions provide an economical, space-saving solution, additionally flange gaskets are typically not required due to the built-in, body seal O-rings
- Resilient soft seats - (PTFE or Buna-N) combined with a gravity assisted disc help to ensure a positive shut-off which creates a bubble tight seal that meets or exceeds API 598 leakage requirements
- Versatile design - This valve can be installed between weld neck or slip-on type companion flanges of different standards, this valve cannot be installed in a vertical pipeline with downward flow
- Fugitive emission design - The one-piece body design eliminates potential leak paths to the environment so there are no body emissions
- PTFE seal
