ThermOmegaTech® 212-211300-125 TV/HAT In-Line Temperature Control Tube Valve, 1/4 in Nominal, Compression End Style, 300 psig Pressure, 300 Series Stainless Steel Body, Domestic
CBPN:257253
MPN:212-211300-125
DESCRIPTION
ThermOmegaTech® Temperature Control Tube Valve, In-Line, Series: TV/HAT, 1/4 in Nominal, Compression End Style, 300 psig Pressure, 150 deg F, Thermal Insulator Handle Actuator, 4.4 in Inlet to Outlet Length, 300 Series Stainless Steel Body, 300 Series Stainless Steel Trim, Kalrez®/PTFE Softgoods, 1 in Dia Dimensions, Domestic, Model 1/4 TV/HAT-125-S6-SW-K
The TV/HAT is a self-actuating fluid control valve ideal for use in conjunction with tracer tubing and tracing systems to keep systems warm, It is often used in winterization tracing, instrument tracing, freeze protection and other applications requiring flow temperature control. Utilizing a thermostatic wax actuator, the TV/HAT valve responds only to fluid temperature to control a system. After condensate forms and cools to the valve's set point, the valve modulates the flow to maintain a constant condensate discharge temperature. During start-up, the TV/HAT is wide open for rapid venting and initial heat-up and then will adjust based on fluid temperature. After shutdown, the valve is self-draining to eliminate freeze damage. For heating of temperature-sensitive instruments or process fluids, the reduced temperature available for tracing simplifies operations and eliminates overheating problems. For other heat transfer fluids, the TV/HAT freeze protection valve maintains a constant discharge temperature, thus providing the benefits of accurate process temperature control and improved efficiency.
ThermOmegaTech® 212-211300-125 TV/HAT In-Line Temperature Control Tube Valve, 1/4 in Nominal, Compression End Style, 300 psig Pressure, 300 Series Stainless Steel Body, Domestic
CBPN:257253
MPN:212-211300-125
DESCRIPTION
ThermOmegaTech® Temperature Control Tube Valve, In-Line, Series: TV/HAT, 1/4 in Nominal, Compression End Style, 300 psig Pressure, 150 deg F, Thermal Insulator Handle Actuator, 4.4 in Inlet to Outlet Length, 300 Series Stainless Steel Body, 300 Series Stainless Steel Trim, Kalrez®/PTFE Softgoods, 1 in Dia Dimensions, Domestic, Model 1/4 TV/HAT-125-S6-SW-K
The TV/HAT is a self-actuating fluid control valve ideal for use in conjunction with tracer tubing and tracing systems to keep systems warm, It is often used in winterization tracing, instrument tracing, freeze protection and other applications requiring flow temperature control. Utilizing a thermostatic wax actuator, the TV/HAT valve responds only to fluid temperature to control a system. After condensate forms and cools to the valve's set point, the valve modulates the flow to maintain a constant condensate discharge temperature. During start-up, the TV/HAT is wide open for rapid venting and initial heat-up and then will adjust based on fluid temperature. After shutdown, the valve is self-draining to eliminate freeze damage. For heating of temperature-sensitive instruments or process fluids, the reduced temperature available for tracing simplifies operations and eliminates overheating problems. For other heat transfer fluids, the TV/HAT freeze protection valve maintains a constant discharge temperature, thus providing the benefits of accurate process temperature control and improved efficiency.
Specifications
Item Features
- Self-operating, no power or signal required
- Eliminates live steam losses
- Downstream thermal actuator for greater sensitivity
- Exclusive Thermoloid® thermal actuator
- Stainless steel body, fittings, spring and plug
- 300 stainless steel operating spring
- Kalrez® body seal/sealing O-ring, PTFE seat seal
- A #20 mesh strainer is recommended
- 125 deg F open/135 deg F close temperature
