ThermOmegaTech IC/FP Valve, Brass

ThermOmegaTech® 180-000000-035 IC/FP Interchangeable Cartridge Thermostatic Freeze Protection Valve, 1/2 in Nominal, NPT End Style, 150 psig Pressure, Brass Body, Domestic

CBPN:257440

MPN:180-000000-035

Price:
$217.00 / EA
Prop 65:

DESCRIPTION

ThermOmegaTech® Thermostatic Freeze Protection Valve, Interchangeable Cartridge, Series: IC/FP, 1/2 in Nominal, NPT End Style, 150 psig Pressure, 200 deg F, Media: Water, Thermal Insulator Handle Actuator, 2.3 in Inlet to Outlet Length, Brass Body, 300 Series Stainless Steel Trim, EPDM Softgoods, Domestic, Model 1/2 IC/FP-35

The IC/FP interchangeable cartridge style Thermostatic Freeze Protection Valve is designed to protect piping in processing plants, safety showers, fire lines and spray nozzles or to be used as a backup protection on traced systems. The IC/FP is preferred for heat traced lines where freeze protection flow is not required unless heat tracing fails. Installed into the lowest point within the heated system, the thermal actuator within the valve is tee'd into the NPT threaded opening with adequate internal clearance to monitor the water temperature. When the water temperature drops below the valve's set point, typically 35 deg F (1.7 deg C), the thermal actuator modulates the valve open. Once the makeup water temperature returns to the safe range (5 deg above the open set point, typically 40 deg F [4.4 deg C] ), the valve then modulates closed, minimizing water waste. Due to the sensing element, the thermal actuator, always being wetted this valve is unaffected by ambient air temperature and opens only when the water is in danger of freezing.

ThermOmegaTech® 180-000000-035 IC/FP Interchangeable Cartridge Thermostatic Freeze Protection Valve, 1/2 in Nominal, NPT End Style, 150 psig Pressure, Brass Body, Domestic

CBPN:257440

MPN:180-000000-035

Price:
$217.00 / EA

Prop 65:
ThermOmegaTech

DESCRIPTION

ThermOmegaTech® Thermostatic Freeze Protection Valve, Interchangeable Cartridge, Series: IC/FP, 1/2 in Nominal, NPT End Style, 150 psig Pressure, 200 deg F, Media: Water, Thermal Insulator Handle Actuator, 2.3 in Inlet to Outlet Length, Brass Body, 300 Series Stainless Steel Trim, EPDM Softgoods, Domestic, Model 1/2 IC/FP-35

The IC/FP interchangeable cartridge style Thermostatic Freeze Protection Valve is designed to protect piping in processing plants, safety showers, fire lines and spray nozzles or to be used as a backup protection on traced systems. The IC/FP is preferred for heat traced lines where freeze protection flow is not required unless heat tracing fails. Installed into the lowest point within the heated system, the thermal actuator within the valve is tee'd into the NPT threaded opening with adequate internal clearance to monitor the water temperature. When the water temperature drops below the valve's set point, typically 35 deg F (1.7 deg C), the thermal actuator modulates the valve open. Once the makeup water temperature returns to the safe range (5 deg above the open set point, typically 40 deg F [4.4 deg C] ), the valve then modulates closed, minimizing water waste. Due to the sensing element, the thermal actuator, always being wetted this valve is unaffected by ambient air temperature and opens only when the water is in danger of freezing.

Specifications

BrandThermOmegaTech®
Weight0.5 lbs
Nominal Size1/2 in
End StyleNPT
Pressure Rating150 psig
Body MaterialBrass
Actuator TypeThermal Insulator Handle
Inlet to Outlet Length2.3 in
Manufacturer NameThermOmegaTech
MediaWater
SeriesIC/FP
Softgoods MaterialEPDM
Temperature Rating200 deg F
Trim Material300 Series Stainless Steel
TypeInterchangeable Cartridge
ApplicationFor the protection of piping, safety showers, solar collectors and piping, condensate systems, fire lines, spray nozzles or as backup protection on traced systems
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsPROP65: This product can expose you to chemicals, for example lead, nickel, acrylonitrile, which are known to the State of CA to cause cancer, birth defects or reproductive harm. For more information, go to www.P65Warnings.ca.gov

Item Features

  • Self-operating, no external power source required
  • Discharges minimum amount of water required
  • Primary protection or fail-safe backup
  • Exclusive self-actuating Thermoloid® blend paraffin wax actuator
  • Stainless steel body, fittings, spring and plug
  • Designed to be tee's into larger diameter pipe lines
  • 300 stainless steel operating spring
  • EPDM seal
  • 35 deg F open/40 deg F close temperature
