Spirax Sarco 62048 6A Air Vent, 3/4 in NPT Connection, 15 psi Pressure, 450 deg F, 7.2 scfm Flow Rate, Cast Iron
CBPN:62311
MPN:62048
Price:
$812.63 / EA
DESCRIPTION
Spirax Sarco Air Vent, 3/4 in NPT, 15 psi, 450 deg F, 7.2 scfm, Cast Iron, 7.25 in H x 3.6 in W
The 6A Air Vent has both a float and a thermostatic bellows for use where air, condensate and steam may be present (as in one pipe steam heating systems.) The 6A will discharge air, while preventing the escape of either condensate or steam. An outlet check valve prevents the re-entry of air.
Spirax Sarco 62048 6A Air Vent, 3/4 in NPT Connection, 15 psi Pressure, 450 deg F, 7.2 scfm Flow Rate, Cast Iron
CBPN:62311
MPN:62048
Price:
$812.63 / EA
DESCRIPTION
Spirax Sarco Air Vent, 3/4 in NPT, 15 psi, 450 deg F, 7.2 scfm, Cast Iron, 7.25 in H x 3.6 in W
The 6A Air Vent has both a float and a thermostatic bellows for use where air, condensate and steam may be present (as in one pipe steam heating systems.) The 6A will discharge air, while preventing the escape of either condensate or steam. An outlet check valve prevents the re-entry of air.
Specifications
Brand: Spirax Sarco
Weight: 4.7 lbs
Connection Type: 3/4 in NPT
Pressure Rating: 15 psi
Temperature Rating: 450 deg F
Flow Rate: 7.2 scfm
Material: Cast Iron
Dimensions: 7.25 in H x 3.6 in W
Manufacturer Name: Spirax-Sarco Inc
Application: Venting air from one-pipe steam heating systems or other applications where air must be removed from a space containing both steam and condensate
Standards and Approvals: ASTM A126 Class B Body
Item Features
- Saturated steam temperature at limiting operating conditions
- 450 deg F maximum allowable temperature
- 125 psig maximum allowable pressure
- Chromated cadmium plated steel with PTFE seat Steel sealing nut
- Stainless steel internals
