Spirax Sarco 1488190, CA14 Liquid Drain Trap, 3/4 in, NPT, 135 mm L, 14 bar, Austenitic Stainless Steel
CBPN:102881
MPN:1488190
DESCRIPTION
Spirax Sarco Liquid Drain Trap, 3/4 in Nominal, NPT, 135 mm Length, 14 bar, Austenitic Stainless Steel, 200 deg C, 97 mm W x 162 mm H
The CAS14 and CAS14S are austenitic stainless steel ball float gas /air drain traps. They provide efficient condensate drainage from compressed air and other gas systems, allowing the process to operate to its optimum potential. The connections are in the vertical plane for flow downwards. Body and cover castings are produced by a TUV approved supplier in accordance with AD-Merkblatt WO/TRD100.
Spirax Sarco 1488190, CA14 Liquid Drain Trap, 3/4 in, NPT, 135 mm L, 14 bar, Austenitic Stainless Steel
CBPN:102881
MPN:1488190
DESCRIPTION
Spirax Sarco Liquid Drain Trap, 3/4 in Nominal, NPT, 135 mm Length, 14 bar, Austenitic Stainless Steel, 200 deg C, 97 mm W x 162 mm H
The CAS14 and CAS14S are austenitic stainless steel ball float gas /air drain traps. They provide efficient condensate drainage from compressed air and other gas systems, allowing the process to operate to its optimum potential. The connections are in the vertical plane for flow downwards. Body and cover castings are produced by a TUV approved supplier in accordance with AD-Merkblatt WO/TRD100.
Specifications
Item Features
- Fitted with a FKM valve cone 1/2 in and 3/4 in
- This product fully complies with the requirements of the European pressure equipment directive 97/23/EC
- Spirax Sarco® offers a wide variety of liquid drainers for removing liquids from gases and timed controlled solenoid valves for liquid removal on compressed air systems
- PN25 body design conditions
- 25 bar g Maximum allowable pressure
- 300 deg C Maximum allowable temperature
- 1 to 0.6 Specific gravity
- 14 to 5 bar Maximum differential pressure
- Stainless steel internals
- Inline horizontal piping configuration
