Spirax Sarco 1454051, FTS14-14 Ball Float and Thermostatic Steam Trap, 3/4 in, FNPT, 225 deg C, 200 psig, 316 Austenitic Stainless Steel
CBPN:179720
MPN:1454051
DESCRIPTION
Spirax Sarco Ball Float and Thermostatic Steam Trap, 3/4 in Nominal, NPT, 135 mm Length, 200 psig, 316 Austenitic Stainless Steel, 225 deg C, 97 mm H
The FTS14 is an austenitic stainless steel ball float steam trap with an integral automatic air vent. It provides efficient condensate drainage and prompt air removal to ensure process equipment operates to its maximum potential. As standard the FTS14 has horizontal connections with flow from right to left (R-L). However its unique design allows the cover to be simply rotated to provide horizontal left to right (L-R) and vertical up or vertical down configurations.
Spirax Sarco 1454051, FTS14-14 Ball Float and Thermostatic Steam Trap, 3/4 in, FNPT, 225 deg C, 200 psig, 316 Austenitic Stainless Steel
CBPN:179720
MPN:1454051
DESCRIPTION
Spirax Sarco Ball Float and Thermostatic Steam Trap, 3/4 in Nominal, NPT, 135 mm Length, 200 psig, 316 Austenitic Stainless Steel, 225 deg C, 97 mm H
The FTS14 is an austenitic stainless steel ball float steam trap with an integral automatic air vent. It provides efficient condensate drainage and prompt air removal to ensure process equipment operates to its maximum potential. As standard the FTS14 has horizontal connections with flow from right to left (R-L). However its unique design allows the cover to be simply rotated to provide horizontal left to right (L-R) and vertical up or vertical down configurations.
Specifications
Item Features
- Maximum allowable pressure: 25 barg at 50 deg C
- Maximum allowable temperature: 300 deg C
- Maximum cold hydraulic test pressure: 37.5 barg
- Maximum operating temperature: 225 deg C at 19 barg
- PN25 Body design conditions
