Spears® 468-291

Spears® 468-291 Pipe Saddle Clamp, 2-1/2 x (2) 1-1/2 in Nominal, Socket Connection, 1-3/4 in Dia Hole, PVC, Buna O-Ring, SCH 40/STD Domestic

CBPN:275406

UPC:054211790243

MPN:468-291

Price:
$67.23 / EA

DESCRIPTION

Spears® Pipe Saddle, Clamp-On, 2-1/2 x (2) 1-1/2 in Nominal, Socket, 1-3/4 in Hole Dia, SCH 40/STD, 235 psi, Zinc Bolt, PVC Clamp, 4 in W x 4-1/16 in D, White, Domestic

All PVC schedule 40 white fittings shall be produced by Spears® Manufacturing Company from PVC Type I cell classification 12454, conforming to ASTM D1784. All injection molded PVC Schedule 40 white fittings shall be certified for potable water service by NSF® International and manufactured in strict compliance to ASTM D 2466. All fabricated fittings shall be produced in accordance with Spears® General Specifications for Fabricated Fittings.

Spears® 468-291 Pipe Saddle Clamp, 2-1/2 x (2) 1-1/2 in Nominal, Socket Connection, 1-3/4 in Dia Hole, PVC, Buna O-Ring, SCH 40/STD Domestic

CBPN:275406

MPN:468-291

UPC:054211790243

Price:
$67.23 / EA

Spears logo

DESCRIPTION

Spears® Pipe Saddle, Clamp-On, 2-1/2 x (2) 1-1/2 in Nominal, Socket, 1-3/4 in Hole Dia, SCH 40/STD, 235 psi, Zinc Bolt, PVC Clamp, 4 in W x 4-1/16 in D, White, Domestic

All PVC schedule 40 white fittings shall be produced by Spears® Manufacturing Company from PVC Type I cell classification 12454, conforming to ASTM D1784. All injection molded PVC Schedule 40 white fittings shall be certified for potable water service by NSF® International and manufactured in strict compliance to ASTM D 2466. All fabricated fittings shall be produced in accordance with Spears® General Specifications for Fabricated Fittings.

Specifications

BrandSpears®
Weight1.17 lbs
Nominal Size2-1/2 x (2) 1-1/2 in
Connection TypeSocket
Clamp MaterialPVC
Schedule RatingSCH 40/STD
Bolt MaterialZinc
ColorWhite
Dimensions4 in W x 4-1/16 in D
Hole Diameter1-3/4 in
Manufacturer NameSpears Manufacturing
Pressure Rating235 psi
TypeClamp-On
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM D1784/2466 | NSF Approved

Item Features

  • Exceptional chemical and corrosion resistance
  • High temperature ratings
  • Lower installation costs
  • Higher flow capacity
  • Additional fabricated configurations through 36 in
  • Advanced design specialty fittings
  • Buna-N O-ring seal and zinc plated hardware
