Spears® 467S-575SR

Spears® 467S-575SR Pipe Saddle Clamp, 8 x 1 in, Special Reinforced FNPT Connection, PVC, Buna O-Ring, SCH 40/STD Domestic

CBPN:275292

UPC:054211324479

MPN:467S-575SR

Price:
$309.45 / EA

DESCRIPTION

Spears® Pipe Saddle, Clamp-On, 8 x 1 in Nominal, Special Reinforced FNPT, SCH 40/STD, 150 psi, Stainless Steel Bolt, PVC Clamp, 10-1/8 in W x 8-1/2 in D, White, Domestic

All PVC schedule 40 white fittings shall be produced by Spears® Manufacturing Company from PVC Type I cell classification 12454, conforming to ASTM D1784. All injection molded PVC Schedule 40 white fittings shall be certified for potable water service by NSF® International and manufactured in strict compliance to ASTM D 2466. All fabricated fittings shall be produced in accordance with Spears® General Specifications for Fabricated Fittings.

Spears® 467S-575SR Pipe Saddle Clamp, 8 x 1 in, Special Reinforced FNPT Connection, PVC, Buna O-Ring, SCH 40/STD Domestic

CBPN:275292

MPN:467S-575SR

UPC:054211324479

Price:
$309.45 / EA

Spears logo

DESCRIPTION

Spears® Pipe Saddle, Clamp-On, 8 x 1 in Nominal, Special Reinforced FNPT, SCH 40/STD, 150 psi, Stainless Steel Bolt, PVC Clamp, 10-1/8 in W x 8-1/2 in D, White, Domestic

All PVC schedule 40 white fittings shall be produced by Spears® Manufacturing Company from PVC Type I cell classification 12454, conforming to ASTM D1784. All injection molded PVC Schedule 40 white fittings shall be certified for potable water service by NSF® International and manufactured in strict compliance to ASTM D 2466. All fabricated fittings shall be produced in accordance with Spears® General Specifications for Fabricated Fittings.

Specifications

BrandSpears®
Weight9.57 lbs
Nominal Size8 x 1 in
Connection TypeSpecial Reinforced FNPT
Clamp MaterialPVC
Schedule RatingSCH 40/STD
Bolt MaterialStainless Steel
ColorWhite
Dimensions10-1/8 in W x 8-1/2 in D
Manufacturer NameSpears Manufacturing
Pressure Rating150 psi
TypeClamp-On
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM D1784/2466 | NSF Approved

Item Features

  • Exceptional chemical and corrosion resistance
  • High temperature ratings
  • Lower installation costs
  • Higher flow capacity
  • Additional fabricated configurations through 36 in
  • Advanced design specialty fittings
  • Buna-N O-ring seal and stainless steel hardware
