Spears® 2022-030

Spears® 2022-030 Gate Valve, 3 in Nominal, Socket End Style, PVC Body, EPDM Softgoods, Handwheel Actuator, Domestic

CBPN:236752

UPC:054211518373

MPN:2022-030

Price:
$885.89 / EA

DESCRIPTION

Spears® Gate Valve, 3 in Nominal, Socket End Style, 150 psi Pressure, 140 deg F, Handwheel Actuator, PVC Body, PVC Trim, EPDM O-Ring Softgoods, 6-11/16 in Diameter Hand Wheel, Gray, Domestic

This solid, proven design is well suited for a variety of chemical, industrial and irrigation applications. Spears® Gate Valves are feature-packed with a variety of end connector options. Individual special features are found in each size range 1/2 in through 2 in, 2-1/2 in and 3 in, and in the full featured Heavy Industrial 4 in valve. See Spears® plug gate valves for 6 in size.

Spears® 2022-030 Gate Valve, 3 in Nominal, Socket End Style, PVC Body, EPDM Softgoods, Handwheel Actuator, Domestic

CBPN:236752

MPN:2022-030

UPC:054211518373

Price:
$885.89 / EA

Spears logo

DESCRIPTION

Spears® Gate Valve, 3 in Nominal, Socket End Style, 150 psi Pressure, 140 deg F, Handwheel Actuator, PVC Body, PVC Trim, EPDM O-Ring Softgoods, 6-11/16 in Diameter Hand Wheel, Gray, Domestic

This solid, proven design is well suited for a variety of chemical, industrial and irrigation applications. Spears® Gate Valves are feature-packed with a variety of end connector options. Individual special features are found in each size range 1/2 in through 2 in, 2-1/2 in and 3 in, and in the full featured Heavy Industrial 4 in valve. See Spears® plug gate valves for 6 in size.

Specifications

BrandSpears®
Weight9.1 lbs
Nominal Size3 in
End StyleSocket
Body MaterialPVC
Softgoods MaterialEPDM O-Ring
Actuator TypeHandwheel
ColorGray
Hand Wheel Diameter6-11/16 in
Manufacturer NameSpears Manufacturing
Pressure Rating150 psi
Temperature Rating140 deg F
Trim MaterialPVC
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM Specified | NSF Approved

Item Features

  • Tapered wedge with specially designed sealing surface
  • Non-rising stem design
  • O-ring stem seals instead of packing
  • Positive grip, high impact polypropylene handwheel operator
  • Fully serviceable, replaceable components accessible without valve removal
  • SCH 80
  • Valves are assembled with silicone free, water soluble lubricant
