CRANE® 428-1/4 Gate Valve, 1/4 in Nominal, FNPT End Style, 125 lb, Bronze Body, Handwheel Actuator
CBPN:13419
MPN:428-1/4
Price:
$172.73 / EA
DESCRIPTION
CRANE® Gate Valve, Series: 428, 1/4 in Nominal, FNPT End Style, 200 psi Pressure, 125 lb Pressure Class, -20 to 150 deg F, Handwheel Actuator, 1.81 in Inlet to Outlet Length, 4.96 in Top to Inlet Center, Bronze Body, Copper Silicon Bronze Trim, Graphite Asbestos Free Packing Softgoods, 1-3/4 in Diameter Hand Wheel
CRANE® bronze gate valves have stood up to commercial and industrial services for more than a century.
CRANE® 428-1/4 Gate Valve, 1/4 in Nominal, FNPT End Style, 125 lb, Bronze Body, Handwheel Actuator
CBPN:13419
MPN:428-1/4
Price:
$172.73 / EA
DESCRIPTION
CRANE® Gate Valve, Series: 428, 1/4 in Nominal, FNPT End Style, 200 psi Pressure, 125 lb Pressure Class, -20 to 150 deg F, Handwheel Actuator, 1.81 in Inlet to Outlet Length, 4.96 in Top to Inlet Center, Bronze Body, Copper Silicon Bronze Trim, Graphite Asbestos Free Packing Softgoods, 1-3/4 in Diameter Hand Wheel
CRANE® bronze gate valves have stood up to commercial and industrial services for more than a century.
Specifications
Brand: CRANE®
Weight: 0.7 lbs
Nominal Size: 1/4 in
End Style: FNPT
Pressure Class: 125 lb
Body Material: Bronze
Softgoods Material: Graphite Asbestos Free Packing
Actuator Type: Handwheel
Hand Wheel Diameter: 1-3/4 in
Inlet to Outlet Length: 1.81 in
Manufacturer Name: Crane ChemPharma Energy
Pressure Rating: 200 psi
Series: 428
Temperature Rating: -20 to 150 deg F
Top to Inlet Center: 4.96 in
Trim Material: Copper Silicon Bronze
Standards and Approvals: ASTM B62 C83600 Body | ASTM B-371 69400 Stem | MSS SP-80 Type 2
Item Features
- Threaded bonnets
- Rising stem
- Highly specified and proven performer for commercial and industrial piping application
- Wide option range seat, disc, trims, and connection type
