Apollo™ 61YLF19101

Apollo™ 61YLF-191-01 61YLF Y-Pattern Swing Check Valve, 1/4 in Nominal, NPT End Style, 125 lb, Bronze Body, Domestic

CBPN:179480

UPC:670750686238

MPN:61YLF19101

Price:
$92.96 / EA
Prop 65:

DESCRIPTION

Apollo™ 61YLF19101, Swing Check Valve, Y-Pattern, Series: 161T-LF, 1/4 in Nominal, NPT End Style, 200 psi CWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, Yes Low Lead Compliance, 2.6 gpm Flow Rate, Media: Steam, 2.14 in Inlet to Outlet Length, Bronze Body, Brass/Bronze Trim, 1.51 in H Dimensions, Domestic

The lead free Apollo™ Model 161T-LF (61YLF Series) Swing Check provides a reliable, long lasting, Made in the USA alternative to globally sourced check valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality materials. The Apollo™ swing check may be installed in either horizontal or vertical orientation with upward flow.

Apollo™ 61YLF-191-01 61YLF Y-Pattern Swing Check Valve, 1/4 in Nominal, NPT End Style, 125 lb, Bronze Body, Domestic

CBPN:179480

MPN:61YLF19101

UPC:670750686238

Price:
$92.96 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ 61YLF19101, Swing Check Valve, Y-Pattern, Series: 161T-LF, 1/4 in Nominal, NPT End Style, 200 psi CWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, Yes Low Lead Compliance, 2.6 gpm Flow Rate, Media: Steam, 2.14 in Inlet to Outlet Length, Bronze Body, Brass/Bronze Trim, 1.51 in H Dimensions, Domestic

The lead free Apollo™ Model 161T-LF (61YLF Series) Swing Check provides a reliable, long lasting, Made in the USA alternative to globally sourced check valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality materials. The Apollo™ swing check may be installed in either horizontal or vertical orientation with upward flow.

Specifications

BrandApollo™
Weight0.64 lbs
Nominal Size1/4 in
End StyleNPT
Pressure Class125 lb
Low Lead ComplianceYes
Body MaterialBronze
Dimensions1.51 in H
Flow Rate2.6 gpm
Inlet to Outlet Length2.14 in
Manufacturer NameApollo Conbraco
MediaSteam
Pressure Rating200 psi CWP
Series161T-LF
Temperature Rating-20 to 406 deg F
Trim MaterialBrass/Bronze
TypeY-Pattern
Warranty5 Years
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASME B1.20.1 | ASME B1.20.1 | ASTM B584-C89836 Body | CSA B51 Canadian Registration No. 0C14667 | C27451 Lead-Free Seat | Complies with Federal Public Law 111-380 | ANSI 3rd Party Approved | MSS SP-80 Design and Tested | MSS SP-139 | NSF/ANSI 372 Lead-Free | NSF/AND 61 | PROP65: Cancer and Reproductive Harm

Item Features

  • Renewable bronze seat disc
  • Dezincification resistant bronze construction
  • 100% factory tested per MSS SP-139
  • Cast, machined and assembled in the USA
  • Brass seat/Bronze seat disc
  • Lead free - The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
