Apollo™ 36LF-104-02 Direct Acting Pressure Reducing Valve, 3/4 in, Single Union NPT, 10 to 35 psig, Bronze Body, Domestic
CBPN:247053
UPC:670750795572
MPN:36LF10402
Price:
$389.01 / EA
Prop 65:
DESCRIPTION
Apollo™ 36LF10402, Pressure Reducing Valve, Direct Acting, Series: 36LF, 3/4 in Nominal, Single Union NPT End Style, 10 to 35 psi Pressure, 33 to 180 deg F, Media: Water, 5-5/8 in Inlet to Outlet Length, Bronze Body, EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring Softgoods, 2-3/4 in D x 5-7/8 in H Dimensions, Domestic
Apollo™ Model PR (36 Series) Pressure Reducing Valves are designed to protect residential and commercial water distribution systems by controlling excessive pressures. The valves are built for long reliable service with proven ASTM grade materials including a bronze body and stainless steel strainer.
Apollo™ 36LF-104-02 Direct Acting Pressure Reducing Valve, 3/4 in, Single Union NPT, 10 to 35 psig, Bronze Body, Domestic
CBPN:247053
MPN:36LF10402
UPC:670750795572
Price:
$389.01 / EA
Prop 65:
DESCRIPTION
Apollo™ 36LF10402, Pressure Reducing Valve, Direct Acting, Series: 36LF, 3/4 in Nominal, Single Union NPT End Style, 10 to 35 psi Pressure, 33 to 180 deg F, Media: Water, 5-5/8 in Inlet to Outlet Length, Bronze Body, EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring Softgoods, 2-3/4 in D x 5-7/8 in H Dimensions, Domestic
Apollo™ Model PR (36 Series) Pressure Reducing Valves are designed to protect residential and commercial water distribution systems by controlling excessive pressures. The valves are built for long reliable service with proven ASTM grade materials including a bronze body and stainless steel strainer.
Specifications
Brand: Apollo™
Weight: 3.4 lbs
Nominal Size: 3/4 in
End Style: Single Union NPT
Pressure Range: 10 to 35 psi
Body Material: Bronze
Dimensions: 2-3/4 in D x 5-7/8 in H
Inlet to Outlet Length: 5-5/8 in
Manufacturer Name: Apollo Conbraco
Media: Water
Series: 36LF
Softgoods Material: EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring
Temperature Rating: 33 to 180 deg F
Trim Material: EPDM/Brass
Type: Direct Acting
Application: Residential and Commercial Applications
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASSE 1003 | ASTM B584 Bronze Body/Cover | ASTM B16 Stem | CSA B356 | FDA Approved | UPC Listed | PROP65: Cancer and Reproductive Harm
Item Features
- Corrosion resistant bronze body and bonnet
- 100% factory tested, preset to 50 psi
- Integral stainless steel strainer
- Balanced piston design
- Internal thermal expansion by-pass
- Nitrile O-ring
- EPDM seat disc/brass stem
- No guage
- No option
