Apollo™ 13-202-B-6

Apollo™ 13202B06 13 Low Pressure Safety Relief Valve, 1 in Nominal, MNPT x FNPT End Style, 6 psi Pressure, Bronze Body, Domestic

CBPN:246959

UPC:670750312472

MPN:13-202-B-6

Price:
$114.94 / EA
Prop 65:

DESCRIPTION

Apollo™ 13202B06, Safety Relief Valve, Low Pressure, Series: 13, 1 in Nominal, MNPT x FNPT End Style, 6 psi Pressure, 250 deg F, Media: Steam, Bronze Body, TFE Seat Softgoods, 3.87 in H Dimensions, Domestic

The Apollo® 13 series bronze low pressure steam safety valve is designed to meet ASME Section IV code requirements for protection of steam heating boilers, systems and similar equipment.

Apollo™ 13202B06 13 Low Pressure Safety Relief Valve, 1 in Nominal, MNPT x FNPT End Style, 6 psi Pressure, Bronze Body, Domestic

CBPN:246959

MPN:13-202-B-6

UPC:670750312472

Price:
$114.94 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ 13202B06, Safety Relief Valve, Low Pressure, Series: 13, 1 in Nominal, MNPT x FNPT End Style, 6 psi Pressure, 250 deg F, Media: Steam, Bronze Body, TFE Seat Softgoods, 3.87 in H Dimensions, Domestic

The Apollo® 13 series bronze low pressure steam safety valve is designed to meet ASME Section IV code requirements for protection of steam heating boilers, systems and similar equipment.

Specifications

BrandApollo™
Weight1.1 lbs
Nominal Size1 in
End StyleMNPT x FNPT
Set Pressure6 psig
Body MaterialBronze
Dimensions3.87 in H
FinishBronze
Manufacturer NameApollo Conbraco
MediaSteam
Pressure Rating6 psi
Series13
Softgoods MaterialTFE Seat
Temperature Rating250 deg F
TypeLow Pressure
ApplicationLow Pressure Steam Heating And Supply Boiler
Warranty5 Years
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM B584 Body | ASME Section IV Heating Boilers | CRN 0G8547.5C | HV/NB Certified | PROP65: Cancer and Reproductive Harm

Item Features

  • Flat seat, PTFE faced disc for positive seal
  • Standard set pressure of 15 psig
  • Positive drainage of condensate from seat area
  • No 13-101 is top outlet discharge
  • Corrosion resistant construction
  • Compact top outlet design option
  • Stainless steel spring
