ALOYCO 2317C02060 FIG 2317 Globe Valve, 6" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Plug Type Disc
CBPN:265836
MPN:2317C02060
Price:
$14303.10 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
DESCRIPTION
ALOYCO Globe Valve, Figure 2317, 6 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Rising Handwheel, Plug Type Disc
ALOYCO 2317C02060 FIG 2317 Globe Valve, 6" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Plug Type Disc
CBPN:265836
MPN:2317C02060
Price:
$14303.10 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
DESCRIPTION
ALOYCO Globe Valve, Figure 2317, 6 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Rising Handwheel, Plug Type Disc
Specifications
Brand: Aloyco®
Weight: 317.5 lbs
Nominal Size: 6 in
End Style: Flanged
Pressure Class: 300 lb
Body Material: Stainless Steel
Actuator Type: Handwheel
Hand Wheel Diameter: 13.8 in
Inlet to Outlet Length: 17.5 in
Manufacturer Name: Crane ChemPharma Energy
Softgoods Material: PTFE
Top to Inlet Center: 28 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
- Recessed Retained Gasket
- Plug Type Disc
