ALOYCO 2317C02014 FIG 2317 Globe Valve, 1-1/2" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Plug Type Disc
CBPN:265832
MPN:2317C02014
Price:
$1646.05 / EA
DESCRIPTION
ALOYCO Globe Valve, Figure 2317, 1-1/2 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Rising Handwheel, Plug Type Disc
ALOYCO 2317C02014 FIG 2317 Globe Valve, 1-1/2" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Plug Type Disc
CBPN:265832
MPN:2317C02014
Price:
$1646.05 / EA
DESCRIPTION
ALOYCO Globe Valve, Figure 2317, 1-1/2 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Rising Handwheel, Plug Type Disc
Specifications
Brand: Aloyco®
Weight: 28.3 lbs
Nominal Size: 1-1/2 in
End Style: Flanged
Pressure Class: 300 lb
Body Material: Stainless Steel
Actuator Type: Handwheel
Hand Wheel Diameter: 7.9 in
Inlet to Outlet Length: 9 in
Manufacturer Name: Crane ChemPharma Energy
Softgoods Material: PTFE
Top to Inlet Center: 10.7 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
- Recessed Retained Gasket
- Plug Type Disc
