ALOYCO 114SC02010 FIG 114 Gate Valve, 1" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Solid Wedge Disc
CBPN:248502
MPN:114SC02010
Price:
$687.05 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 114, 1 in Nominal, Socket Weld, 150 lb, OS&Y, Raised Face, CF3M Stainless Steel Body, Bolted Bonnet, Rising Stem, Solid Wedge Disc
ALOYCO 114SC02010 FIG 114 Gate Valve, 1" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Solid Wedge Disc
CBPN:248502
MPN:114SC02010
Price:
$687.05 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 114, 1 in Nominal, Socket Weld, 150 lb, OS&Y, Raised Face, CF3M Stainless Steel Body, Bolted Bonnet, Rising Stem, Solid Wedge Disc
Specifications
Brand: Aloyco®
Weight: 9.8 lbs
Nominal Size: 1 in
End Style: Socket Weld
Pressure Class: 150 lb
Body Material: Stainless Steel
Softgoods Material: PTFE
Actuator Type: Handwheel
Hand Wheel Diameter: 3.9 in
Inlet to Outlet Length: 3.54 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 9.1 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34, API 603
Item Features
- Solid Wedge Disc (1/2 - 1")
- Flexible Wedge Disc (1-1/2 - 2")
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
